Hangzhou Zon Packaging Machinery Co.,Ltd
| Place of Origin: | China |
|---|---|
| Brand Name: | ZON PACK |
| Certification: | CE Certification |
| Model Number: | ZH-DW300 |
| Minimum Order Quantity: | 1 Set |
| Price: | 5000-6000USD per set |
| Packaging Details: | Wooden case |
| Delivery Time: | 20-25 Working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 300 Sets per month |
| Name: | High Speed Check Weigher | Weighing Range: | 50-5000g |
|---|---|---|---|
| Power Supply: | 220V | Display Type: | Touch Screen |
| Scale Interval: | 0.2g | Belt Speed: | 70m/min |
| Rejector: | Air Blow, Pusher, Shifter | Frame Material: | SUS304 |
| High Light: | 5000g High speed checkweigher,High speed checkweigher system,5000g check weigher scale |
||
70m/min High speed checkweigher scale with rejector system for food
Technical Feature
1. 7" color touch screen, Intelligent compact design construction;
2. Auto program setting adjust for more stability and easier to operate;
3. Apply HBM load cell ensure high accuracy and stability (original from Germany);
4. Solid SUS304 structure ensure stable performance and precise weighing;
5. Reject arm, air blast or pneumatic pusher for selecting;
6. USB flash drive supported to store data
7. Touch panel based user interface with multi-language supported
| Technical Specification | |||||||
| Model | ZH-DW160 | ZH-DW230S | ZH-DW230L | ZH-DW300 |
ZH-DW400 |
ZH-DW500 | ZH-DW600 |
| Weighing Range | 10-600g | 20-2000g | 20-2000g | 50-5000g | 0.2-10kg | 0.5-20kg | 10-50kg |
| Scale Interval | 0.05g | 0.1g | 0.1g | 0.2g | 1g | 1g | 5g |
| Best Accuracy | ±0.1g | ±0.2g | ±0.2g | ±0.5g | ±1g | ±2g | ±5g |
| Max Speed | 250 pcs/min | 200 pcs/min | 155pcs/min | 140pcs/min | 105pcs/min | 75pcs/min | 75pcs/min |
| Belt Speed | 70m/min | 70m/min | 70m/min | 70m/min | 70m/min | 60m/min | 60m/min |
| Product Size | 200mm (L) 150mm (W) |
250mm (L) 220mm (W |
350mm (L) 220mm (W) |
400mm (L) 290mm (W) |
550mm (L) 390mm (W) |
700mm (L) 490mm (W) |
1000mm (L) 590mm (W) |
| Weighing Platform Size |
280mm (L) 160mm (W) |
350mm (L) 230mm (W) |
450mm (L) 230mm (W) |
500mm (L) 300mm (W) |
650mm (L) 400mm (W) |
800mm (L) 500mm (W) |
1200mm (L) |
| No. of Sorting Segment | 2 Segments or 3 Segments | ||||||
| Rejector | air blow, Pusher, shifter | ||||||
| Power Parameter | 220V/110V 50/60Hz | ||||||
| Protection Level | IP30/IP54/IP66 | ||||||
| Frame Material | SUS304 | ||||||
Application of the Check Weigher
A check weigher is an automatic machine for checking the weight of packaged commodities. It is normally
found at the off going end of a production process and is used to ensure that the weight of a pack of the
commodity is within specified limits.
